TUBE / PROFILE PUNCHING MACHINE SMS ENGINEERING
orCall +359 24917190
Specifications
| Manufacturer | SMS Engineering SRL |
| Model | PA 80 Profile & Tube punching Machine |
| Condition | Used |
| Lubrication | aut. lubrication on punching tools |
| Tooling included | typical set for rectangular profile 50 X 50 mm |
| Stockl ist | 1399 |
| Y.O.M. | 11/06 |
| Machine condition | Perfect less than 200 hours of operation |
| Control | PLC Siemens |
| Technical | specifications |
| Max tube dia | 80 mm |
| Max rectangular dimension | 80 X 80 mm |
| Max profile length | 3000 mm |
| Workpiece | holding hydraulic double oposite side |
| Tilting unit | for rectangular sections included 90 ° |
| Typical set of equipment for operation per size/type | grips, mandrel, punch holder, punch |
| Time per each punch | 2 sec |
| Loading / unloading time per profile | 10 sec |
| Sku | 1919 |
Description
Capabilities
- synchronous punching of two oposite sides
- single side punching
- synchronous operation with different operations per side
